Small Continuous Laser Cleaning Machine Working Efficiency and Principles

Laser cleaning is a non-contact, eco-friendly method that uses high-energy laser pulses to remove contaminants (rust, paint, oil, oxides, etc.) from surfaces without damaging the substrate.

  • laser power1.5KW
  • size870mm*830mm*950mm
  • weight150.0 kg
price$$3000.0/Set - $3120.0/Set. More Earlier you buy, more discount you have.

Small Continuous Laser Cleaning Machine: Working Efficiency and Principles

1. Working Principle

Laser cleaning is a non-contact, eco-friendly method that uses high-energy laser pulses to remove contaminants (rust, paint, oil, oxides, etc.) from surfaces without damaging the substrate.

Key Processes:

  • Laser Absorption: The laser beam is absorbed by the contaminant layer, causing rapid heating.

  • Vaporization/Ablation: Contaminants evaporate or are ejected as plasma due to thermal expansion.

  • Minimal Substrate Impact: The underlying material remains unaffected if the laser parameters (wavelength, power, pulse duration) are properly set.

Types of Lasers Used:

  • Fiber Lasers (common in small machines): High efficiency, compact, 1064 nm wavelength.

  • Pulsed or Continuous-Wave (CW) Lasers: CW lasers provide steady cleaning, while pulsed lasers offer controlled ablation.

2. Working Efficiency

The efficiency of a small continuous laser cleaning machine depends on several factors:

a) Cleaning Speed:

  • Typically 0.5–10 m²/h (varies with laser power, dirt type, and desired cleanliness).

  • Higher power (e.g., 200W–500W) increases speed but may raise costs.

b) Laser Power:

  • 50W–500W for small machines (higher power = faster cleaning).

  • Lower power (50W–100W) is suitable for delicate surfaces (e.g., electronics, cultural relics).

c) Surface Material & Contaminant Type:

  • Easy to Remove: Dust, light rust (faster cleaning).

  • Hard to Remove: Thick paint, heavy oxidation (slower, may require multiple passes).

d) Automation & Scanning System:

  • Manual vs. Robotic Arm: Automated systems improve consistency and speed.

  • Galvo Scanners: High-speed laser scanning for precision cleaning.

e) Energy Efficiency:

  • Fiber lasers convert ~30–50% of electrical energy into laser light, reducing operational costs compared to sandblasting or chemical cleaning.

3. Advantages Over Traditional Methods

  • Non-abrasive: No damage to the base material.

  • Eco-friendly: No chemicals or media (like sand or water).

  • Precision: Can clean intricate patterns without masking.

  • Low Maintenance: No consumables (except electricity and occasional lens cleaning).

4. Applications

  • Electronics: PCB cleaning, solder removal.

  • Automotive: Paint stripping, rust removal.

  • Aerospace: Coating removal, pre-weld cleaning.

  • Cultural Heritage: Gentle restoration of artifacts.

5. Limitations

  • High Initial Cost: More expensive than sandblasting machines.

  • Reflective Materials: Metals like copper and aluminum may require adjusted settings.

  • Safety Measures: Requires protective eyewear and proper ventilation for fumes.
